Facilities

dc power supply

VARIABLE DC POWER SUPPLY: 330V, 152A

dynamometer

30kW DYNAMOMETER FOR TORQUE TESTING

torque testing

POWER SUPPLIES UPTO 50A, 80V


torque-measuring

TORQUE MEASURING SETUP

torque-measuring1

BACK EMF MEASURING SETUP

torque-measuring2

Votsch Climatic Chamber

winding-machine

WINDING MACHINE

hot-air-oven

HOT AIR OVEN

lcr-meter

µOHM METER & LCR METER

Name of the Equipment :

  • Single spindle coil winding machine
  • Soldering station WS51
  • Refrigerator with stand
  • Digital Multimeter
  • Software Magnet 2D and 3D
  • Software Motor Solve
  • Insulation Tester
  • 4½ digit Micro Ohm meter
  • Digital Storage Oscilloscope
  • GM 07 Guass Meter
  • ABB AC motor with drive
  • Weighing machine DS 852
  • GW instek insulation tester
  • Horizontal Laminar Flow Table
  • Microscope Stereo Zoom
  • Infrared Thermometer
  • DC Power Supply
  • Desiccators with Vacuum pump
  • Rotary Vacuum pump
  • CNC Coil winding machine
  • Climatic Chamber Freight, customs and handling
  • Stepper motor,
  • Motor test setup,Freight, customs and handling
  • BLDC drive
  • Engraving tools
  • Torque Transducer
  • Drilling machine
  • Die grinder
  • AC/DC clamp meter.
  • Torque screw drivers
  • Hot Air Oven
  • Dynamometer meter test bench
  • Digital clamp meter
  • 30KW Dynamometer
  • Function Generator
  • EDM drilling machine
  • EDM wire cut machine
  • Laser marking machine
  • HP-8 Horizontal/Vertical Rotary Table & 6” chuck
